Metal Power Rack + Power Indicator Lights 12-015

19inch Horizontal Power Distribution Unit

Safety:

  • With  On/off switch and circuit breaker it can be more safer, with power indicator light, easily aware of product working situation. - Optional
  • With Surge protection indicator light, and master On/off switch, enhance Safety identification level, easily aware of product working situation. Optional
  • With heavy duty cord, avoid the electric wire go off due to wire twisted.

Convenient:

  • Ideal for use of multiple convenience outlets for powering various of equipment.
  • Just one click switch to turn on/off to control  power strip power.
  • Long type power strip, can fix much power issues of electronic or machine which cannot be used due to electric cord range.
  • The long wire of power strip solution can totally solve the short wire problem of using electronic device.
  • 1 U Metal Chassis with built in mounting ears design for rack.

Appearance:

12-015 is a metal power rack, simple, compact and easy design, not too much complicated appearance.

Textured aluminum shell,light weight, easy to move, durability greatly enhanced.

Model  Outlets   Amps   Cord Length  Protection  Amp/Volt. Meter
Surge VPR
12-015 Max. 24 24A 1.5m~4.5m - - -
 12-015S  Max. 20 24A 1.5m~4.5m  Optional   L-N 400  -

      19inch Rackmount Power Distribution Unit

 PRODUCT  INFORMATION

 Model no.   12-015 / 12-015S
 Color  Customization
 Material of  Construction  1U Metal Chassis with built-in mount means
 Product  Dimensions  482.60 mm x 49.5 mm x 44 mm
 AC POWER /
 SURGE PROTECTION
 Surge Protection  Yes - max. 3000 Joules Rating - Optional
 Voltage  120 Vac
 UL 1449 VPR  L-N 400V
 Duty cycle current  3KA
 Current  24A  (single loop max.12A, 120Vac)
 Frequency  Compatibility  50/60 Hz
 Output  Receptacles  NEMA 5-15R or NEMA 5-15R Duplex Receptacles or IEC C13
 Outlet numbers  12-015 max. 24,   12-015S max. 20
 Plug Type  NEMA 5-30P or NEMA L5-30P
 Input Cord Length  As order requirement. (As laws and regulations is Max. 4.5M,  Min.1.5M)
 CERTIFICATIONS  Certifications  Tested to UL 60950-1, 2nd Edition, 2011-12-19
 CSA C22.2 No. 60950-1-07, 2nd Edition, 2011-12
 RoHS Compliant
