Safety:
Convenient:
Appearance:
RT half rack is simple, long and easy design, easy sharing more outlets with others and other device, not too much complicated appearance.
PRODUCT INFORMATION |
Model no. | 14-028-12, 14-028-12S | 14-028-16, 14-028-16S | 14-028-I12, 14-028-I16 |
14-028-i13/ Color | Customization | Customization | Customization | |
Material of Construction | Steel | Steel | Steel | |
AC POWER / SURGE PROTECTION |
Surge Protection | YES- OPTIONAL | YES- OPTIONAL | - |
Voltage | 125 Vac | 125 Vac | 100-240 Vac | |
UL 1449 VPR | L-N 500V | L-N 500V | - | |
Duty cycle current | 3 KA | 3 KA | - | |
Current | 12A | 16A | 12A / 16A | |
Frequency Compatibility | 60 Hz | 60 Hz | 60 Hz | |
Output Receptacles | NEMA 5-15P | NEMA 5-20P | IEC13 / 1EC19 | |
Outlet numbers | 9 | 9 | IEC13:8 , IEC19:5 | |
Plug Type | NEMA 5-15P | NEMA 5-20P | IEC13 / 1EC19 | |
Input Cord Length | Customization. As laws and regulations is Max. 4.5M, Min.1.5M | Customization. As laws and regulations is Max. 4.5M, Min.1.5M | Customization. As laws and regulations is Max. 4.5M, Min.1.5M | |
Input Phase | Single-Phase | Single-Phase | Single-Phase | |
CERTIFICATIONS | Certifications | UL 60950-1, 2nd Edition, 2011-12-19 (Information Technology Equipment - Safety - Part 1: General Requirements) | UL 60950-1, 2nd Edition, 2011-12-19 (Information Technology Equipment - Safety - Part 1: General Requirements) | UL 60950-1, 2nd Edition, 2011-12-19 (Information Technology Equipment - Safety - Part 1: General Requirements) |
CAN/CSA C22.2 No. 60950-1-07, 2nd Edition, 2011-12 (Information Technology Equipment - Safety - Part 1: General Requirements) | CAN/CSA C22.2 No. 60950-1-07, 2nd Edition, 2011-12 (Information Technology Equipment - Safety - Part 1: General Requirements) | CAN/CSA C22.2 No. 60950-1-07, 2nd Edition, 2011-12 (Information Technology Equipment - Safety - Part 1: General Requirements) | ||
RoHS Compliant | RoHS Compliant | RoHS Compliant |
* 1 Master On/off switch with built-in circuit breaker
