MSDM 19inch Horizontal Power Distribution Unit

Safety:

  • With 1 master On/off switch and circuit breaker it can be more safer, with power indicator light, easily aware of product working situation. - Optional
  • With Amperage/Boltage meter, monitor unit condition any time.
  • With Surge protection indicator light, and master On/off switch, enhance Safety identification level, easily aware of product working situation. Optional
  • With heavy duty cord, avoid the electric wire go off due to wire twisted.

Convenient:

  • Ideal for use of multiple convenience outlets for powering various of equipment.
  • Just one click master switch to turn on/off to control whole power strip power.
  • Long type power strip, can fix much power issues of electronic or machine which cannot be used due to electric cord range.
  • The long wire of power strip solution can totally solve the short wire problem of using electronic device.
  • 1 U Metal Chassis with built in mounting ears design for rack.

Appearance:

MSDM is a metal power rack, simple, compact and easy design, not too much complicated appearance.

Textured aluminum shell,light weight, easy to move, durability greatly enhanced.




 PRODUCT  INFORMATION

 Model no.   MSDM
 Color  Customization
 Material of  Construction  Metal(Iron)
 AC POWER /
 SURGE PROTECTION
 Surge Protection  Yes - max. 3000 Joules Rating - OPTIONAL
 Voltage  125 Vac
 UL 1449 VPR  L-N 500V
 Duty cycle current  3KA
 Current  12A or 16A (as order requirement)
 Frequency  Compatibility  60 Hz
 Output  Receptacles  NEMA 5-15R (duplicate - optional) or
 NEMA 5-20R (duplicate - optional)
(as order requirement)
 Outlet numbers  1 to 20
 Plug Type  NEMA 5-15P or NEMA 5-20P (as order requirement)
 Input Cord Length  As order requirement. (As laws and regulations is Max. 4.5M,  Min.1.5M)
 Input Phase  Single-Phase
 CERTIFICATIONS  Certifications  Tested to UL 60950-1, 2nd Edition, 2014-10-14
 CAN/CSA C22.2 No. 60950-1-07, 2nd Edition, 2014-10
 RoHS Compliant

1 Master On/off switch with built-in circuit breaker

* NEMA 5-15R OR NEMA5-20R Duplicate Outlet - OPTIONAL
