Safety:
Convenient:
Appearance:
MSP is a metal power rack, simple, compact and easy design, not too much complicated appearance.
Textured aluminum shell,light weight, easy to move, durability greatly enhanced.
|
PRODUCT INFORMATION |
Model no. | MSP |
| Color | Customization | |
| Material of Construction | Metal(Iron) | |
| AC POWER / SURGE PROTECTION |
Surge Protection | Yes - max. 3000 Joules Rating - OPTIONAL |
| Voltage | 125 Vac | |
| UL 1449 VPR | L-N 500V | |
| Duty cycle current | 3KA | |
| Current | 12A | |
| Frequency Compatibility | 60 Hz | |
| Output Receptacles | NEMA 5-15R (duplicate - optional) | |
| Outlet numbers | 1 to 20 | |
| Plug Type | NEMA 5-15P | |
| Input Cord Length | As order requirement. (As laws and regulations is Max. 4.5M, Min.1.5M) | |
| Input Phase | Single-Phase | |
| CERTIFICATIONS | Certifications | Tested to UL 60950-1, 2nd Edition, 2014-10-14 |
| CAN/CSA C22.2 No. 60950-1-07, 2nd Edition, 2014-10 | ||
| RoHS Compliant |
* 1 Master On/off switch with built-in circuit breaker
* NEMA 5-15R OR NEMA5-20R Duplicate Outlet - OPTIONAL
