190people have viewed this product
Filter Bank ( always ) + Suger Protector 06-047
3 Outlet Power Conditioner- Always On Filter Bank, Switched Filter Bank
- 4200 Joules max.
- Combo On/Off Switch/Breaker
- Metal Housing
.jpg)
Safety:
- With 1 master On/off switch and circuit breaker it can be more safer, with power indicator light, easily aware of product working situation.
- With Surge protection, enhance Safety identification level.
Convenient:
- A compact power conditioner ideally for use behind the flat TV pane.l
- Just one click master switch to turn on/off to control whole power strip power.
Appearance:
06-047 is simple, compact and easy design, not too much complicated appearance.
|
PRODUCT INFORMATION |
Model no. | 06-047 |
| Color | Customization, | |
| Material of Construction | Aluminuml | |
| Product Weight | 0.68KGs | |
| Product Dimensions | 255 mm x 92 mm x 38 mm | |
| AC POWER / SURGE PROTECTION |
Surge Protection | Yes - 4200 Joules Rating |
| Voltage | 125Vac | |
| UL 1449 VPR | L-N 330V | |
| Duty cycle current | 3KA | |
| Current | 12A | |
| Frequency Compatibility | 60 Hz | |
| Output Receptacles | NEMA 5-15R | |
| Outlet numbers | 3 (1 outlet alwasys on bank and 2 outlets switched bank) | |
| Plug Type | NEMA5-15P | |
| Input Cord Length | As order requirement. (As laws and regulations is Max. 4.5M, Min.1.5M) - Fixed or Detachable input cord |
|
| Input Phase | Single-Phase | |
| CERTIFICATIONS | Certifications | Tested to UL 60950-1, 1st Edition, 2007-10-31 |
| CSA C22.2 No. 60950-1-03, 1st Edition, 2006-07 | ||
| UL 1283, Fifth Edition | ||
| UL 1449, Third Edition | ||
| C22.2, No. 8-M1986, Fourth Edition and Canadian Technical Information Letter I-11B and A-24 | ||
| RoHS Compliant |
