Safety:
Convenient:
Appearance:
FFPI is simple, compact and easy design, not too much complicated appearance.
Textured aluminum shell,light weight, easy to move, durability greatly enhanced.
PRODUCT INFORMATION |
Model no. | FFPI | FFPI |
Color | Customization | Customization | |
Material of Construction | Aluminum | Aluminum | |
Product Dimensions | As spec of order requirement, length Min. 12 inches, Max. 77 inches | As spec of order requirement, length Min. 12 inches, Max. 77 inches | |
AC POWER / SURGE PROTECTION |
Surge Protection | - | Yes - 1650 Joules Rating |
Voltage | 125Vac | 125Vac | |
UL 1449 VPR | - | L-N 500V, L-G 500V, N-G 500V OR L-N 700V -OPTIPNAL | |
Duty cycle current | - | 3KA | |
Current | 15A or 20A (as order requirement) | 15A or 20A (as order requirement) | |
Frequency Compatibility | 60Hz | 60 Hz | |
Output Receptacles | NEMA 5-15R or NEMA 5-20R (as order requirement) | NEMA 5-15R or NEMA 5-20R (as order requirement) | |
Outlet numbers | 4 to 32 (as order requirement) | 4 to 32 (as order requirement) | |
Plug Type | NEMA 5-15P or NEMA 5-20P (as order requirement) | NEMA 5-15P or NEMA 5-20P (as order requirement) | |
Input Cord Length | Length between 0.61 and 7.6 meters. | Length between 0.61 and 7.6 meters. | |
Input Phase | Single-Phase | Single-Phase | |
USB CHARGING (optional) |
Ports | 1 set for 2 ports | 1 set for 2 ports |
Output Voltage | 5Vdc | 5Vdc | |
Output Current | 1 set for 3.1A | 1 set for 3.1A | |
CERTIFICATIONS | Certifications | Tested to UL 962A, Fourth Edition, dated February 22, 2016. | UL 962A, Second Edition, U. S. National Standard for Furniture Power Distribution Units |
- | UL 1449, Third Edition, Standard for Surge Protective Devices | ||
C22.2 No. 21_95, Eighth Edition, Canadian National Standards Cord Sets and Power Supply Cords | CSA C22.2 No. 21-95, Eighth Edition, Canadian Standards for Cord Sets and Power Supply Cords | ||
- | CSA C22.2 No. 8-M1986, Fourth Edition, Electromagnetic Interference (EMI) Filters | ||
- | C22.2 No.42-10, General Use Receptacles, Attachment Plugs, and Similar Wiring Devices, Seventh Edition, latest revision dated November, 2010 | ||
- | ECN 516/I-11B, Surge/Transient Voltage Suppressors, dated September 2, 1986. | ||
RoHS Compliant | RoHS Compliant |
* 1 Master On/off switch with built-in circuit breaker - Optional
